HANPOSE HPD332 2.2A 8-36V Stepper Motor Driver For 20 28 35 42 Motor

HPD332 is a two-phase stepper motor driver designed for controlling stepper motors. It is compatible with 20, 28, 35, 39, and 42 4, 6, and 8-wire stepper motors.

• Type: Two-phase stepper motor driver
• Model: HPD332
• Operating voltage: 8-36V DC
• Output current: Peak current of 2.2A
• Subdivisions: 16 selectable subdivisions
• Current settings: 16 selectable current levels
• Protection features: Overvoltage, undervoltage, phase current, and total current overcurrent protection
• Signal input: Single-ended, pulse + direction, and double pulse
• Maximum input pulse frequency: 300KHz
• Temperature range: Operating temperature of 0-50°C
• Storage temperature: -20 to 65°C
• Humidity range: 40-90% RH
• Vibration tolerance: 10-55 Hz/0.15mm
• Weight: 180g
• Construction: Multi-layer boards with surface mount sealing
• Environmental requirements: Avoid dust, oil, corrosive gases, excessive humidity, and strong vibration
