DC12V High-Fidelity 2.1 Three-Channel Speaker Amplifier Board DIY Audio Modification Module
DC12V High-Fidelity 2.1 Three-Channel Speaker Amplifier Board DIY Audio Modification Module
SKU: EDA0090349
Regular price
€14,95
Regular price
Sale price
€14,95
Duties & Import Tax Information
Duties are only included if shown at checkout. Otherwise, your local government may apply customs fees, which your courier will collect directly from you before delivery.
In Stock
CHN
This item is shipped from China.
Processed in 0–3 days
Quantity
Couldn't load pickup availability
Shipping info
To find all available shipping methods and exact delivery times, add the product to your cart and check using our shipping calculator.
30-day returns
Fast refunds: Once we receive and check your item, we aim to process your refund within 48 hours.
Return postage: Just changed your mind? You'll need to cover the return postage. If the item arrived faulty, we'll cover the cost to get it back to us.
Your details are safe
We treat your data the way we'd want ours treated. Your payment details are locked down with bank-level encryption. We never actually see your credit card numbers, and we will absolutely never sell your personal information.
Product Details
1. Power Supply: DC 6.5-15V (depending on the required output power). Power adapters, switching power supplies, and batteries are all suitable. A current of 3A or higher is recommended.
2. Bass Output Power: Maximum 25W. A 4-6 inch, 4-6 ohm, 20-50W subwoofer is recommended.
3. Left and Right Channel Output Power: 6W + 6W. 2-4 inch, 4-8 ohm, 3-25W full-range speakers are recommended. The above power requirements assume a power supply of approximately 13.5V.
4. The left and right channels use the high-fidelity audio-specific chip TDA1517P as the output stage, providing truly high-quality sound.
5. PCB Material: FR-4 fiberglass board, thickness: 1.6mm
6. Board Dimensions: 63 x 45 x 20mm, excluding the potentiometer handle length.
7. Potentiometer Shaft Distance: 24mm. The potentiometer mounting hole diameter should be 7mm.
8. Input Interface: 3.5mm jack socket
2. Bass Output Power: Maximum 25W. A 4-6 inch, 4-6 ohm, 20-50W subwoofer is recommended.
3. Left and Right Channel Output Power: 6W + 6W. 2-4 inch, 4-8 ohm, 3-25W full-range speakers are recommended. The above power requirements assume a power supply of approximately 13.5V.
4. The left and right channels use the high-fidelity audio-specific chip TDA1517P as the output stage, providing truly high-quality sound.
5. PCB Material: FR-4 fiberglass board, thickness: 1.6mm
6. Board Dimensions: 63 x 45 x 20mm, excluding the potentiometer handle length.
7. Potentiometer Shaft Distance: 24mm. The potentiometer mounting hole diameter should be 7mm.
8. Input Interface: 3.5mm jack socket
