100kHz-149MHz FM SDR/DSP2 Radio Receiver, Specification: Main Unit
100kHz-149MHz FM SDR/DSP2 Radio Receiver, Specification: Main Unit
In stock
Couldn't load pickup availability
Shipping Information
Shipping Information
FAST DELIVERY to UK & 40+ countries.
Delivery: Typically 4-8 working days total including 1-3 days handling to the UK (estimated times for other locations shown at checkout)
Import duties and taxes may apply depending on destination. UK orders under £135 or less ship DDP with no extra charges at delivery. Orders over £135 may have import duties.
Ships from China. Your order will be processed and dispatched from the warehouse within 1–3 days if you order by 12 AM London.
30-Day Money-Back Guarantee
30-Day Money-Back Guarantee
Return unused items within 30 days (you pay return shipping). Faulty items covered, any costs to you will be refunded.
Right Part Guarantee
Right Part Guarantee
Get exactly what you ordered or your money back, including shipping. 30 days, no questions asked.
Easy Returns
Easy Returns
Start your return online in seconds. No forms, no hassle.
Trusted by DIY & repair professionals in 40+ countries
• Compatibility: 100kHz-149MHz SDR/DSP2
• Material: IPS LCD
• Key feature: Touchscreen control
• Color/Variant: N/A
• Intended use: Everyday use
• Category: Consumer Electronics
1. Display technology: 4.3-inch IPS 800x480 resolution DC dimming high-brightness LCD
2. Control method: resistive touchscreen + rotary encoder
3. Frequency range: 100kHz – 149MHz
4. Operating modes: CW, AM, SSB (LSB/USB), WFM, FM broadcast stereo (headphones required)
5. Frequency step: 1Hz/10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz
6. Spectrum bandwidth: 192kHz, 128kHz, 64kHz, FFT real-time spectrum display
7. Antenna interface: BNC male connector, 50ohm impedance, input power -20dBm (MAX)
8. Reference crystal oscillator: TCXO 26MHz
9. Audio interface: supports standard 3.5mm headphones or CTIA (American standard) interface headphones
10. Speaker power: 3W, 4ohm multimedia speaker
11. Charging port: USB Type-C, 5.0V/2A
12. Current consumption: approximately 250mA @ 5V
13. Battery capacity: 5000mAh/3.7V, 18.5Wh
14. Usage time: approximately 10-12 hours, depending on volume and brightness settings
15. Channel storage: 99 preset channels, including station name, frequency, and demodulation method
16. RF preamplifier gain: fixed 20dB
17. Circuit type: zero Intermediate Frequency (ZIF)
18. Sideband suppression: 50dB
19. Dimensions: 140 x 74 x 22mm
20. Weight: approximately 315g (main unit only)
