2009.0 Motorcycle Rectifier For 31600-MY7-305 AP9100424 31600-KY2-703 31600-MV4-010
2009.0 Motorcycle Rectifier For 31600-MY7-305 AP9100424 31600-KY2-703 31600-MV4-010
🖤🔴 Add 2+ items to your cart for an early Black Friday discount! Hurry, stock is almost gone! 🔴🖤
Couldn't load pickup availability
Shipping Guarantee
Shipping Guarantee
FREE SHIPPING on all UK orders. Fully Insured.
Handling time 1 - 3 working days. (Buy2fix has to process your order and put all your items through its strict quality-control tests.)
Transit time 5 - 10 working days.
Return Guarantee
Return Guarantee
For whatever reason if you are unsatisfied with your order within 7 days you can return it to us in new condition for a refund minus the shipping charges.
DOA Guarantee
DOA Guarantee
If your item arrives damaged, please contact us within 7 days and provide clear and valid proof. Buy2fix will make compensation based on the damage situation.
Missing/Wrong Items Guarantee
Missing/Wrong Items Guarantee
If you receive a parcel with missing/incorrect/secondary packing items, please contact us within 7 days of delivery and provide the relevant proof. Buy2fix will make compensation based on the damage situation.
1. Weight: 115G
2. Output voltage: 14.5V
3. Category: single-phase full-wave rectifier
Installation precautions:
1. The rectifier should be installed in a location with good ventilation and good heat dissipation. High temperature will be generated when the rectifier is working, and poor heat dissipation will damage the rectifier
2. The installation steps of the rectifier are to connect the AC input line, the positive and negative output are not connected, start the locomotive, measure the positive and negative output voltage, and when the voltage range is reasonable, plug in the positive and negative wires, and then test the positive and negative of the battery or rectifier If the voltage range is unreasonable, stop using it and give feedback. The entire installation process should be recorded and saved.
3. Note that the rectifier should be closely attached to the frame when installing it, which is good for heat conduction. You can also add thermally conductive glue between the rectifier and the frame
4. No other wires should be pressed between the rectifier and the frame
5. There should be a fuse fuse between the positive outlet of the rectifier and the battery to prevent the rectifier from being damaged when the voltage is too large and other electrical components will be burned.
Applicable models:
For Honda CB S 600 2004 2007 31600-KFG-861
For Honda CB F 600 2004 31600-KFG-861
For Honda CB F 400 1989 1990 31600-KY2-702
For Honda CB Nighthawk A/AC 250 1991 2000 31600-KBG-008
For Honda CB HORNET 600 1998 2006 31600-KFG-861
For Honda CBR F2/F3/F4 600 1991 2000 31600-MV4-010
For Honda CBR A/AC 900 1993 1999 31600-MV4-010
For Honda CBR SE Hurricane A/AC 600 1998 31600-MV4-010
For Honda CBR SJR Replica A/AC 600 1996 31600-MV4-010
For Honda CBR RR W X SC33 900 1992 1999 31600-MV4-010
For Honda CBR Hurricane 600 1991 2000 31600-MV4-010
For Honda NTV AUVILLE 650 1998 2001 31600-KFG-861
For Honda NV C2 V W X 750 1997 2004 31600-MV4-010
For Honda VT SHADOW 750 1997 2003 31600-MV4-010
For Honda VT CA/CAC/CD/CD2 750 1998 2000 31600-MV4-010
For Honda VTR F A/AC 1000 1997 2000 31600-MV4-010
For Honda VTR NC29 / NC30 / NC31 1000 2002 2005 31600-MV4-010
For Honda XLV Vara ro 1000 1999 2000 31600-MV4-010
