HDMI 2.0 Audio Extractor Support R/L Output And Volume Control 4K/60Hz Audio Splitter EU Plug

The HDMI 2.0 Audio Extractor is a splitter that allows audio extraction from HDMI devices. It supports various resolutions and features volume control, making it suitable for everyday use.

• Product Type: Splitter
• Compatibility: HDMI devices
• Key Feature: Volume control
• HDCP Version: HDCP 2.2
• Input/Output Resolution: 1080p/60fps, 4K/30fps, 4K/60fps
• Deep Color Mode: 4K/60fps-YUV444-8 bit, 4K/60fps-YUV422-12 bit 2160p, 10/12 bits, 50/60Hz
• HDMI Maximum Bandwidth: 600MHz
• HDMI Maximum Baud Rate: 18Gbps
• Input and Output TMDS Signal: 0.5-1.5Vp-p (TTL)
• Input and Output DDC Signal: 5Vp-p (TTL)
• DAC Sampling Frequency: 32-192 KHz
• DAC Bit Rate: 16-24 bits
• RCA Analog Output (1kHz 0dB): 1V RMS
• 3.5mm Audio Port Maximum Output Level: 6.5Vp-p
• 3.5mm Audio Port Maximum Output Power: 32 ohms 30mW
• Signal-to-Noise Ratio 0dB (CC1R/ARM): ≥ 90dB
• Distortion: ≤ 0.1%
• Frequency Response: 20Hz-20kHz
• HDMI Input/Output Cable Distance: ≤ 3m AWG26 HDMI standard cable
• Maximum Operating Current: 400mA
• Power Adapter Specifications: AC 100V-240V 50/60Hz, DC 5V/1A
• Operating Temperature Range: -10 to 55 degrees Celsius
• Storage Temperature Range: -20 to 60 degrees Celsius
• Operating Humidity Range: 10-90% RH (no condensation)
• Storage Humidity Range: 5-95% RH (no condensation)
• Size: Approximately 10 x 9.5 x 2 cm
• Net Weight: Approximately 117 g
• Packing List: HDMI audio extractor x 1, DC5V/1A power adapter x 1, USB power cable x 1, User manual x 1
