WAVESHARE Luckfox PicoKVM Lightweight IP KVM Remote Management Tool Basic Version

Name: WAVESHARE Luckfox PicoKVM Lightweight IP KVM Remote Management Tool Basic Version
Brand: WAVESHARE
SKU: TBD0602862501
Availability: InStock

$82.00

Sale Sold out

In stock

Fast Delivery

30-Day Returns

1-Year Warranty

Shipping Information

FAST DELIVERY to UK & 40+ countries.

Delivery: Typically 4-8 working days total including 1-3 days handling to the UK (estimated times for other locations shown at checkout)

Import duties and taxes may apply depending on destination. UK orders under £135 or less ship DDP with no extra charges at delivery. Orders over £135 may have import duties.

Ships from China. Your order will be processed and dispatched from the warehouse within 1–3 days if you order by 12 AM London.

Full shipping policy →

30-Day Money-Back Guarantee

Return unused items within 30 days (you pay return shipping). Faulty items covered, any costs to you will be refunded.

Full policy →

Right Part Guarantee

Get exactly what you ordered or your money back, including shipping. 30 days, no questions asked.

Easy Returns

Start your return online in seconds. No forms, no hassle.

Return portal →.

Trusted by DIY & repair professionals in 40+ countries

• Product type: Lan Cable and Tools
• Brand: WAVESHARE
• Compatibility: PicoKVM
• Material: Lightweight
• Key feature: Remote management tool
• Color/Variant: Basic Version
• Intended use: Remote device management
• Category: Computer & Networking

1. Luckfox PicoKVM is a lightweight IP KVM management tool that supports remotely acquiring the screen of a target device and simulating HID input over the network, enabling contactless maintenance and management of development boards, computers, and servers. This product features stable, low-latency video capture and remote control capabilities, making it widely applicable to scenarios such as remote computer control and server maintenance. 2. Onboard HDMI input interface: Can be recognized as a monitor by a computer for screen capture.3. Onboard USB interface: Supports mouse, keyboard, and U disk device emulation.3. Onboard 100Mbps Ethernet interface: Used for video and control signal transmission.4. 1.54-inch touch screen: Displays IP address, connection status, and system operating status (Basic version does not have a screen).5. Micro SD card slot: Supports storage expansion.6. 10 expansion interfaces: Can be used for host power on/off control.Function Support:1. Main Controller: RV1106G32. Core: 1 x A7@1.2G3. Memory: 256M DDR34. Hard Drive: 8G eMMC5. System: PicoKVM6. Resolution: 1080P@60fps7. Video Encoding: H2648. Video Latency: 80ms ~ 200ms9. Audio Transmission: Supported10. UEFI/BIOS Support: Yes11. Emulated USB Keyboard and Mouse: Yes12. Emulated USB Storage: Yes13. UEFI/BIOS Access: Yes14. Wake-on-LAN (WOL): Yes15. Web Terminal: Yes16. Custom Scripts: Yes17. Serial Terminal: 1 channel18. Storage Expansion: Micro SD card19. Power Control: GPIO control20. Ethernet: 100Mbps21. LCD Display: 1.54-inch 240 × 240 resolution touch screen (Only the full version includes a screen)22. Power Input: Type-C23. Dimensions:-- Full version: 48.50 × 48.50 × 29.00 (mm)-- Basic version: 44.00 x 42.00 x 23.60 (mm)
